Turgo Turbine Design for Increased Efficiency
River based hydro turbines are rotating machines that transform the kinetic energy of moving water into the mechanical energy of a rotating shaft. There are many shapes and turbine designs using nozzles, buckets or wheels. The turgo turbine design is an impulse turbine which can operate with good flow rates.
Although large wooden waterwheels of various types and designs have been used for many centuries, they are not generally suitable for generating electricity as part of a small hydro power system. The main reason for this is that they are large, heavy, rotate at low speeds and would require complex gearing or pulleys to enable the drive shaft to reach speeds high enough to run an electrical generator.
Hydro turbines on the other hand are capable at rotating at much higher speeds, are much lighter, smaller, easier to fabricate and more compact than the traditional wooden waterwheel. Although based on the same principals as a classic water wheel, water turbines are far more suited for smaller hydro electricity generation schemes as they are far more efficient in terms of water usage over a wider range of head and available flow rates.
The turbine is the heart of any small or micro hydro installation. Water under pressure contains vast quantities of energy and turbines convert that energy into rotating mechanical shaft power, and to do just that there are two main types of water turbine design:
- Impulse Turbines – Impulse turbines operate in free air and convert the kinetic energy of one or more pressurised jets of water into mechanical energy.
- Reaction Turbines – Reaction turbines operate fully submerged in water and convert the potential energy of the pressurized water into mechanical energy.
While there are many different water turbine designs readily available in the market place, their selection in any given small or micro hydro installation will depend on several factors. These include the head of water available, the volume of flow (flow rate), and required power output. One very common and efficient micro turbine design is the Turgo Hydro Turbine.
What is the Design of a Turgo Turbine
The beauty of the turgo turbine lies in its simple design and robust construction requiring minimal maintenance. They are very suitable for micro-hydro and pico-hydro (100–200 watt power output) off-grid installations since they can operate efficiently over a wide range of flow rates and head heights.
The turgo turbine is an impulse turbine design the same as Pelton and Cross Flow turbines where the kinetic energy of the water entering is extracted before leaving the turbine at atmospheric pressure from the opposite side of the runner.
Thus its design uses a special nozzle at the end of a pipe to convert the flow of the water into a high pressure jet. This jet of water is then directed at an angle of about 20 degrees towards the turbines internal water wheel which uses spoon-shaped blades to capture the jet of water. These blades are specially shaped so that the pressurised water enters several blades at a time on one side and then drops away and exits on the other converting the kinetic energy of the water jet into rotational shaft power.
This tangential flow of the water across the turbines runner means that the waste water leaves the blades without interfering with the incoming water jet as is the case with other impulse turbines.
The result is that a Turgo turbine can have a smaller diameter runner and blades producing a highly efficient impulse turbine for an equivalent power input allowing it to rotate at much higher speeds to drive an electrical generator.
Disadvantages of the Turgo Turbine Design
One of the disadvantages of the turgo turbine design is that to generate sufficient nozzle pressure and rotate the turbine runner at high speeds, they require more head height than other designs. Therefore, they have to be connected to some form of penstock or pipe in order to channel the water at speed in order for it to function correctly.
However to overcome these limitations, instead of using just one nozzle and water jet to rotate the turbines runner, the turgo turbine can be fitted with multiple nozzles located equally around its circumference. Then a turgo turbine can be equipped with either two, four or six jet nozzles placed around the turbines runner and blades extracting more kinetic energy from the water before too much water splash interference occurs reducing its efficiency.
This increase in the number of water jet nozzles means that the Turgo Turbine can operate under low-head and low-flow conditions making them particularly well suited for run-of-river schemes with large flow variations.
The amount of energy extracted from the water will increase as the power output is proportional to the number of nozzles. Then multi nozzle impulse turbines are ideal for use in stand alone micro hydro DC power systems designed to charge a battery bank or power a home.
Turgo turbine designs represent an improvement in the available shaft power compared to conventional water wheels and other impulse turbine designs. They are generally less expensive to make and with multiple nozzles can handle a greater flow of water, so a smaller turgo turbine can generate the same amount of power as a larger water wheel.
